Copeland 3HP Scroll Compressor ZR36K3-PFJ-522 (Single Phase, R22/R407C)
Copeland 3HP Scroll Compressor ZR36K3-PFJ-522 (Single Phase, R22/R407C) - Image 2
Copeland 3HP Scroll Compressor ZR36K3-PFJ-522 (Single Phase, R22/R407C) - Image 3
Copeland 3HP Scroll Compressor ZR36K3-PFJ-522 (Single Phase, R22/R407C) - Image 4
,

Copeland 3HP Scroll Compressor ZR36K3-PFJ-522 (Single Phase, R22/R407C)

The Copeland Scroll Compressor ZR36K3-PFJ-522 is a highly reliable, 3-Horsepower hermetic compressor designed for residential and light commercial air conditioning systems. Engineered for optimum efficiency and quiet operation, this genuine OEM component features a heavy-duty single-phase motor (PFJ) running on standard 220-240V / 50Hz power. It is ideal for Nigerian climate conditions, offering robust tolerance against harsh operating environments and high-ambient heat.

₦380,000 ₦450,000

Add to cart

Upgrade or repair your cooling systems with the industry standard in HVAC reliability. The Copeland ZR36K3-PFJ-522 utilizes advanced scroll technology to deliver continuous, high-efficiency compression with significantly fewer moving parts than traditional reciprocating compressors. This results in smoother operation, reduced vibration, and lower electricity consumption.

Whether you are managing a commercial facility or providing expert technician services, this compressor ensures seamless drop-in replacement for 36,000 BTU (3 Ton) AC units. It operates seamlessly with R22 and R407C refrigerants and comes pre-configured with standard sweat (stub) connections for a clean, leak-free brazing install.

Technical Specifications

Specification Value
Brand Copeland (Emerson / Copeland Climate Technologies)
Model Number ZR36K3-PFJ-522
Horsepower (HP) 3.0 HP
Cooling Capacity 30,200 BTU/hr (at 50Hz) / up to 36,500 BTU/hr (at 60Hz)
Voltage / Phase 220-240V / 1-Phase / 50Hz (Also rated for 265V / 60Hz)
Refrigerant Compatibility R22, R134A, R407C
Application Type High/Medium Temperature (Air Conditioning & Chillers)
Rated Load Amps (RLA) 16.4 A
Locked Rotor Amps (LRA) 82.0 A
Suction Line Size 3/4″ Stub
Discharge Line Size 1/2″ Stub
Oil Type & Charge Mineral Oil / 38 oz (Initial Charge)

Shipping & Logistics Data

  • Net Weight: 29.5 kg (65 lbs)

  • Gross Shipping Weight (with protective wooden crate/box): ~32.0 kg

  • Estimated Box Dimensions: 30 cm × 30 cm × 50 cm

SKU: COM-COPZR36 Categories: , Tags: , , , , , ,
